| Engine Type |
Single cylinder ,4 stroke ,air-cooled |
| Displacement |
107CC（106.7） |
| Compression Ratio |
9.0:1 |
| MAX POWER OUT |
4.8/8000kw(r/min) |
| Max Torque |
6.9/6500N.m(r/min) |
| Carburetor |
PZ19 |
| Ignition |
AC-CDI |
| Starting System |
Electric |
| Transmission |
CHAIN |
| Suspension / Front |
Spring Shock |
| Suspension / Rear |
Spring Shock |
| Brakes / Front |
Drum brake |
| Brakes / Rear |
Disc brake |
| Tires and Rim/ Front |
145/70-6 off-road tyre,steel rim 20F |
| Tyre and Rim/ Rear |
145/70-6 off-road tyre,steel rim 20F |
| L x W x H |
1250mm×725mm×820mm |
| Carton L x W x H |
1165mm×700mm×640mm |
| Seat Height |
600mm |
| Wheelbase |
830mm |
| Front Wheel tracy |
590mm |
| Rear Wheel Tracy |
550mm |
| Fuel Capacity |
2.2L |
| Net Weight |
73KGS |
| Gross Weight |
91KG |
| Loading |
48/136(20Fcl /40HC) |
| Ground distance |
85MM |
| Max payload |
65Kg |
| Payload of rack（F、R） |
R 10kg |
